• Customized：Customized
• Transport Package：Wood
• Specification：8kVA
• Trademark：BESMA
• Origin：China
• HS Code：8514400090
• Production Capacity：500PCS,Year

Basic Info.

Customized Customized Transport Package Wood Specification 8kVA Trademark BESMA Origin China HS Code 8514400090 Production Capacity 500PCS/Year

Product Description

Features:
1. With high frequency up to 500kHz-900KHz, the quenching thickness can be controlled lower than 1mm, and very thin and tiny parts can be easily heated.
2. IGBT and inverting technologies of third generation been used; Higher reliability and lower maintenace cost.
3. 100% duty cycle, continuous working is allowed at maximum power output.
4. Constant current or constant power status can be selected accordingly to achieve higher heating efficiency;
5. Display of heating power and heating current and oscillating frequency.
6. Simple to install, installation can be done by unprofessional person very easily;
7. Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability.

Model:	6500D
Maximum input power:	6.5KVA
Oscillatging frequency:	0.5 -0.9MHz
Input voltage:	220V, single phase, 50Hz
Duty cycle:	100%
Cooling water desire:	3L/min 0.2-0.4Mpa
Water temperature protection :	<35 degree
Auto heating time, retaining time:	0.1-99.9Sec.
Weight: N. W. (kg) :	controller:15kg ;transformer:3kg
Size(L *W *H):	CON:370x270x130mm ;TRA:165x110x75mm
