• Model NO.：JC2331 JC2332
• Impact Drill Head：Adjustable Drill
• Drill shape：Round
• Condition：New
• Customized：Customized
• Core drill：12-55mm
• Twist drill：1-23mm
• Motor：1500w
• Max. Travel：190mm
• Min. plate thickness：10mm
• Speed：550r,min
• weight：23kg,25kg
• Voltage：110V,220V
• Spindle taper：Morse2#
• Tapping：M22
• Rotation Angle：Left and right 45 degree (JC2332)
• Horizontal Travel(mm)：20mm(JC2332)
• Transport Package：Carton
• Trademark：HOTONMC
• Origin：Shandong, China
• HS Code：8459290000
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. JC2331 JC2332 Impact Drill Head Adjustable Drill Drill shape Round Condition New Customized Customized Core drill 12-55mm Twist drill 1-23mm Motor 1500w Max. Travel 190mm Min. plate thickness 10mm Speed 550r/min weight 23kg,25kg Voltage 110V/220V Spindle taper Morse2# Tapping M22 Rotation Angle Left and right 45 degree (JC2332) Horizontal Travel(mm) 20mm(JC2332) Transport Package Carton Trademark HOTONMC Origin Shandong, China HS Code 8459290000 Production Capacity 50 PCS/Month

Product Description

Magnetic Drill:
Magnetic drill also called Magnetic broach drill or Magnetic drill press. Its performance Principle is the Magnetic base adhesive onto the surface of working metal.Then press the working handle downwards and drill through the heaviest beams and steel plating. The magnetic base adhesive power controlled by electric coil that Electromagnetic.Using annular cutters, these drills can punch up to 1-1/2" diameter holes in steel up to 2" thick. They are built with durability and heavy use in mind and feature powerful motors and strong magnetic bases.

Magnetic Drill Usage:
Magnetic drills is a new type of drilling tools, which construction and design very precision and uniform, very potable and universal drilling machine for its light duty. Magnetic base made it very convenient on working Horizontally(water level), vertically, upwards or in high point. Magnetic drills is an ideal machine in steel construction, industrial construction,engineering,equipment reparation, railways, bridges, ship building, crane, metal working, boilers, machinery manufacturing, environmental protection, oil and gas pip line industries


MODEL	JC2331	JC2332 (The base is rotatable)
Voltage	220V	220V
Motor power (w)	1500	1500
Speed (r/min)	200-550 (6step)	200-550 (6step)
Magnetic adhesion(N)	>15000	>15000
Core drill(mm)	12-55	12-55
Twist drill (mm)	1-23	1-23
Max.Travel(mm)	190	190
Min. plate thickness(mm)	10	10
Spindle taper	Morse2#	Morse2#
Tapping	M22	M22
Weight (kg)	23	25
Rotation Angle	/	Left and right 45°
Horizontal Travel(mm)	/	20

Contact Us:

Andy Wang  TENGZHOU HOTON MACHINERY CO.,LTD   MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
