• Model NO.：QK1313
• Precision of Work Piece：It6-It7
• Sleeve Diameter of Tailstock：100mm
• Length*Width*Height：3600*1750*1910
• Automatic Grade：Automatic
• Precision：High Precision
• Power Source：Electric
• Setting Mode：Floor-Type
• Controlling Mode：CNC
• Certification：SGS, Ce
• Transport Package：Standard Wood Packing
• Specification：CE
• Trademark：Crystal
• Origin：Taian City, Shandong Province, China
• HS Code：8458110090
• Production Capacity：30sets,Month

Technical  specifications

Maximum diameter of lathe bed (mm)

φ610

Maximum tactical diameter

of sliding plate(mm)

φ350

Maximum work-piece length (mm)

1000

Main drive

 Form

Main motor servo  stepless

Rank of spindle speed

No grade

Range of spindle speed(r/min)

50-850 rpm

Terminal structure

C11

Hole diameter of spindle (mm)

Φ140

The maximum diameter of  the tube

135mm

 Power of main motor (KW)

11KW(servo)

Feeding system

Maximum route of  knife rest (mm)

X:310   Z:1150

Speed of quick-travel (mm/min)

X:4000  Z:5000

Resetting accuracy

X:0.012  Z:0.016

Precision of work piece

IT6-IT7

Surface roughness

Ra1.6

Tailstock

Sleeve diameter of tailstock (mm)

Φ75

 Sleeve trip of tailstock (mm)

150

Cone hole taper tailstock's sleeve

MT5

Knife rest

Standard configuration

Four-station vertical

electrical knife rest

Alternative configuration

Horizontal Six-station

electrical knife rest

Resetting accuracy (mm)

0.01

Length of section of knife handle (mm)

30×30

Machine size

weight

Length*width*height

3500×1755×1900

Net weight (Kg)

3500Kg

Standard configuration

CNC System:GSK-980TDC/GSK-980TC3

3 jaw manual double chuck

4 station tool

Manual tailstock

Lighting system

Cooling system

Automatic lubrication system

3 phase 380v 50HzDouble chuckBig spindleServo main motorTaiwan ball screwHigh efficiency

Optional configuration

Siemens system /Fanuc system

Hydraulic chuck/ pneumatic chuck

6-piece electric tool post/8- piece electric tool post
