Hydraulic Sheet Metal Hole Punch Tool
TAIZHOU RUIQI TOOLS CO., LTD.- Tonnage：11 Ton
- Max. Thickness：Iron Sheet 3.2mm , Stainless Steel 1.6mm
- Punching Dies：22 27 34 43 49 60mm
- Transport Package：Plastic Box
- Specification：CE; ISO9001: 2000
- Trademark：TLP
Base Info
- Model NO.：HHK-8B
- Origin：China
- HS Code：84678900
- Production Capacity：500PCS,Month
Description
| Model | Tonnage | Max. stroke |
Max. thickness(mm) |
Punch range |
Punch dies |
G. W. |
Volume |
|
| (T) | (mm) | Stainless steel | Iron Sheet | (mm2) | (mm) | (kg) | (cm) | |
| HHK-8 | 9 | 16 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 10.4 | 45*40*16 |
| HHK-8A | 11 | 20 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 8 | 48*26*14 |
| HHK-8B | 11 | 22 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 13 | 45*40*16 |
| HHK-8C | 11 | 22 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 9 | 50*32*15 |
| HHK-8D | 8 | 22 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 11.6 | 45*40*16 |
| HHK-8E | 8 | 22 | 1.6 | 3.2 | 16-60 | Φ 22Φ 27Φ 34Φ 43Φ 49Φ 60 | 5.5 | 50*30*16 |
| HHK-15 | 13 | 22 | 2 | 4 | 16-114 | Φ 63Φ 76Φ 80Φ 89Φ 100Φ 114 | 27 | 48*26*13 |
