Concrete Drilling Machine
Shanghai Chengxiang Electromechanical Equipment Co., Ltd.- Type：Core Drill
- Classification：Hand Drill
- Applications：Building and Industrial
- Impact Drill Head：Adjustable Drill
- Customized：Customized
- Trademark：CAYKEN
Base Info
- Model NO.：SCY-4050,3C
- Origin：Shanghai
- Production Capacity：50000 Per Year
Description
Basic Info.
Model NO. SCY-4050/3C Origin Shanghai Production Capacity 50000 Per YearProduct Description
Quick Details:Application: Reinforced concrete, stone
Model Number: SCY-4050/3C
Max. Drilling Diameter: 405mm
No-Load Speed: 400/510/630r/min
Rated Input Power: 5180W
| Product Model | SCY-3050/3CE | SCY-3550/3CE | SCY-4050/3CE | SCY-4050/3C |
| Drill Range | 12'' 305MM | 14'' 355MM | 16' 405MM | 16'' 405MM |
| Rated Voltage | 110/220V | 110/220V | 110/220V | 110/220V |
| Rated Frequency | 50-60HZ | 50-60HZ | 50-60HZ | 50-60HZ |
| Rared Input Power | 4650W | 4880W | 5180W | 5180W |
| No-Load Speed | 100-430/550/700R/MIN | 100-420/520/680R/MIN | 100-400/510/630R/MIN | 400/510/630R/MIN |
| Spindle | 1 1/4'' UNC | 1 1/4'' UNC | 1 1/4'' UNC | 1 1/4'' UNC |
