1.5kw 40L Hydraulic Double Active Heavy Duty Electric Pump Zhh700c-10b-II
TAIZHOU YINDU TOOLS CO., LTD.- Transport Package:Steel Box
- Specification:CE
- Trademark:yindu
- Origin:China
Base Info
- Model NO.:ZHH700C-10B-II
- HS Code:8413503990
- Production Capacity:1000 Sets Per Month
Description
Hydraulic single active heavy duty electric pump ZHH700BC-10B-IIPower rating(380V) 1.5KW 1.5KW 2.2KW 3.0KW Working pressure 70MPA 70MPA 70MPA 70MPA Low Flow 10L/min 10L/min 10L/min 10L/min High Flow 1.5L/min 1.5L/min 2.0L/min 3.0L/min Oil capacity 20L 40L 40L 40L Dimension 360*300*560 480*360*660 480*360*700 480*360*700 Weight 45kg 47kg 54kg 56kg Features and functions:
1. Large tonnage double or single acting soleniod valve control electric pump is with high pressure, convenient for maintenance. With manual pedal switches could make jacks move up and down freely. With solenoid valve control oil return.
2. The pump is widely used. It can be used as a source of hydraulic machinery of all kinds of pressure, but also as a variety of high, medium and low pressure hydraulic source experiment.
3. The hydraulic lifting tools, pressure-shaping tools, pipe bender, straightening tools, demolition tools, punching tools could be assembled with this kind of pump.
Manual instructions:
1. Connect hydraulic tools and high pressure tube.
2. Switch on manual or pedal switch to start the motor oil pump.
3. Begin to pump hydraulic tools supporting oil pressure reaches the appropriate location.
4. Press the other end swtich, start pressure release(when run 20 liter pump, it should be open the filler cap so that oil container is ventilating)
1. Large tonnage double or single acting soleniod valve control electric pump is with high pressure, convenient for maintenance. With manual pedal switches could make jacks move up and down freely. With solenoid valve control oil return.
2. The pump is widely used. It can be used as a source of hydraulic machinery of all kinds of pressure, but also as a variety of high, medium and low pressure hydraulic source experiment.
3. The hydraulic lifting tools, pressure-shaping tools, pipe bender, straightening tools, demolition tools, punching tools could be assembled with this kind of pump.
Manual instructions:
1. Connect hydraulic tools and high pressure tube.
2. Switch on manual or pedal switch to start the motor oil pump.
3. Begin to pump hydraulic tools supporting oil pressure reaches the appropriate location.
4. Press the other end swtich, start pressure release(when run 20 liter pump, it should be open the filler cap so that oil container is ventilating)
