• Model NO.：PPAWM-24Ba,32Ba,48Ba
• Welding Power Source：Lincoln, Miller or Chinese Brand (as Per Request)
• Transport Package：Sea Worthy Packing
• Specification：CE, ISO9001, SGS, TUV
• Trademark：QSPT
• Origin：Made in Shanghai, China
• HS Code：8515800090
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. PPAWM-24Ba/32Ba/48Ba Welding Power Source Lincoln, Miller or Chinese Brand (as Per Request) Transport Package Sea Worthy Packing Specification CE, ISO9001, SGS, TUV Trademark QSPT Origin Made in Shanghai, China HS Code 8515800090 Production Capacity 20 Sets/Month

Product Description

Automatic Welding Machine (Cantilever Type)/Automatic Piping Welding Center
Automatic Pipe Welding Machine/Piping Welding Machine
Model No.: PPAWM-16B, PPAWM-24B, PPAWM-32B, PPAWM-40B, PPAWM-48B

Performance features

Pipe Welding Machine, Welding Machine, Automatic Welding Machine, Automatic Pipe Welding Machine, Piping Welding Machine, Pipe Welding Equipment
Welding Efficiency: Excellent (250-500 inch/day, which is 4 multiples higher than the manual welding)
Higher automatic welding qualification rate: 98% min (without re-working for the skilled operator).
Welding procedure:
Application: be widely used in projects with a majority various of butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, pipereducer, pipe-tee, flange-flange and flange-elbow etcOn-line Performance: Excellent (Designed completely as per the on line equipment of the production line)
Application: TIG+MIG+SAW for automatic root pass, fill in & final welding or welding the pipes or the cap welding of the aluminum alloy pipe which need higher quality.
Operability: Good (applicable and easy to operate even if you are a new user within a short period of time).
Surface finishing: Excellent (the welding gun will always be positioned in the optimum position)
Driving Reliability: Good (driven by frictional force, however, it is required to set essential balance weight to offset large bending moment caused by elbows for large diameter pipe, or providing a chain tensioner to improve the reliability of the driving).

Technical parameters

Pipe diameter applicable: DN50-400(φ 60~426); DN50~600(φ 60~610); DN200-800(φ 219-813);
DN400-1000 (φ 426-1016); DN 600-1200 (φ 610-1219)
Pipe wall thickness applicable: 3~60mm
Materials applicable: Carbon steel, alloy steel, stainless steel and cryogenic steel, etc.
Welding line applicable: Various butt welding lines of spool pieces such as pipe-pipe, pipe-elbow, pipe-flange, flange-flange and flange-elbow, etc (a fake pipe transition connection shall be applied if necessary).

Driving System: Driven by Welding Positioner with centering chuck
Clamping system: Clamping by centering chuck with 3 Jaws;
Bracket System: Separate type of trolley matching for welding machine, which may height & length adjustable along the track according to the length of the piping
Counterweight System: No Counterweight
Speed~regulation Mode: VF stepless speed control system
Adjustment Mode: With electric cross regulator
Oscillating system: A product of our patented technology, driven by step motor.
Control system: A product of our patented technology, PLC control with touch screen.
Welding procedure: TIG/MIG/FCAW/SAW (applicable for pipe root run, fill in & final welding)
Welding power: LINCOLN, MILLER OR SAF-PRO DIGI@WAVE500 (As per customer's demand)


Technical Description	Standard Type
Welding Capacity:	250-500 dia-inch/day(4 times higher than the manual welding)
Pipe diameter applicable:	DN50-400/DN50~600/DN200-800mm/DN400-1000/DN600-1200mm
Pipe wall thickness applicable:	3~60mm
Materials applicable:	Carbon Steel, Alloy Steel, Stainless Steel and Cryogenic Steel
Welding procedure:	TIG/MIG/FCAW/SAW (applicable for pipe root pass, fill in & final welding)

 our company is the most innovation ability provider of integrated solutions for piping fabrication, also is the unique provider of professional piping plant design software & management software system and piping equipments in China which included pipe spool fabrication line, cutting equipments, beveling equipments, fitting up equipments, handling equipments, welding equipments.
