• Model NO.：XZ180
• Impact Drill Head：Adjustable Drill
• Drill shape：Round
• Condition：New
• Customized：Customized
• Rated Power：98kw
• (97kw) Engine：(97kw) Engine
• 180kn：180kn
• Usage：Construction
• Transport Package：Nude Packing
• Trademark：EON
• Origin：Xuzhou Jiangsu
• HS Code：8701200000
• Production Capacity：10set,Months

Model
XZ180
Engine

Rated power
kW
97
Max.pullback/thrusting
kN
180/180
Spindle torque(max)
N.m
6000
Spindle speed
r/min
0-140
Backreaming diameter
mm
Ø600
Tubing length(single)
m
3
Tubing diameter
mm
Ø60
Entry angle
°
10-22
Mud flow rate(max)
L/min
250
Mud pressure (max)
bar
80
Overall weight
kg
10000
DIMENSION (LxWxH)
mm
6400×2270×2340(97KW) engine, 180kN of push-pull, 6000N.m of Max.spindle torque, motor dual speed chain push-pull system, self-propelled rubber tracks chassis, automatic loading and unloading drill rod device, rotatable control board, patent technology for floating vice, and onboard high-capacity mud pump (250L/min).
