Precision Dicing Saw for 8" Workpiece Cutting (DS9100)
Nanjing Wotian Technology Co., Ltd.- Application：Silicon, PCB, Ceramic, Glass, Lithium Niobate, etc
- Type：Fixed
- Power Source：Imported Dd Motor
- Customized：Customized
- Condition：New
- Workpiece Size：φ8 ≤250mm X 250mm
Base Info
- Model NO.：DS9100
- Groove Depth：≤4mm or Customize
- Spindle: Revolution Speed Range：6000~60000 Rpm
- Spindle: Output Power：1.8kw
- X Axis: Feed Speed Range：0.1~600mm,S
- Y Axis: Single-Step Accuracy：≤0.002mm,5mm
- Z Axis: Repeatability Accuracy：0.002mm
- Θ Axis: Max. Rotating Angle：380°
- Power Supply：Three Phases, AC380V±10%
- Exhaust Air Rate：5 M3,Min (Anr)
- Transport Package：Standard Export Packing
- Specification：900mm× 1050mm× 1800mm; 1200kg
- Origin：China
- HS Code：84862090
- Production Capacity：200+ Sets,Year
Description
Basic specificationPower supply Three phases, AC380V±10% Compressed air Pressure: 0.5~0.7Mpa; average flow rate 350L/min Cleaning water Pressure: 0.2~0.4Mpa; flow rate 4.0L/min Cooling water Pressure: 0.2~0.4Mpa; flow rate 1.5L/min (0.3MPa/hour) Exhaust air rate 5 m3/min (ANR) Overall dimensions W×D×H 900mm×1050mm×1800 mm Weight 1200kg
• Use clean, oil-free air (dew point below -15, residual oil: 0.1 ppm, and filtration rating: 0.01μm/99.5 % or more).
• Keep room temperature fluctuations within ±1ºC of the set value (Set value should be between 20ºC - 25ºC), indoor humidity no more than 80% and no condensation.
• Keep cutting water and cleaning water 2ºC above room temperature (fluctuations within ±1ºC). Keep temperature of cooling water the same as room temperature.
• The machines should be used in an environment, free from external vibration. Do not install machine near a ventilation opening, heat generation equipment or oil mist generating parts.
• This machine uses water. In case of water leakage, please install the machine on the floor with sufficient waterproofing and drainage treatments.
• Please follow the product manual of our company.
