• Model NO.：OB-5000E
• Drill shape：Round
• Condition：New
• Customized：Customized
• Controlling Mode：Artificial
• Structure：Vertical Drilling Machine
• Layout：Vertical
• Automatic Grade：Automatic
• Precision：Precision
• RoHS：Red
• Transport Package：Woodencase,Carton
• Trademark：OUBAO
• Origin：Shanghai China
• Production Capacity：200sets Rer Month

Basic Info.

Model NO. OB-5000E Drill shape Round Condition New Customized Customized Controlling Mode Artificial Structure Vertical Drilling Machine Layout Vertical Automatic Grade Automatic Precision Precision RoHS Red Transport Package Woodencase/Carton Trademark OUBAO Origin Shanghai China Production Capacity 200sets Rer Month

Product Description

Product model: OB-5000E

Largest drill: 50mm

Rated voltage: 220V

Max attraction: 15500N

Rated input power: 1650W

No-load speed: 0-570r/min

1. High power withsmall size and light weight,

2. with constant power soft-starting and electric stepless speed-regulation,

3. with over-loading protection using electic speed-regulation.

4. High adhesion.

5. with coolant and lubricant integrateddevice

Model	OB-2500	OB-3500	OB-5000	OB-6000	OB-9000	OB-1200
Max Drilling Dia.	ø25MM	ø35MM	ø50MM	ø60MM	ø90MM	ø120MM
Rated Voltage	220V	220V	220V	220V	220V	220V
Magnetic Adhesion	12800N	14000N	15500N	15800N	16800N	19800N
Input Power	1400W	1580W	1650W	1680W	1980W	2580W
No-load Speed	650RPM	600RPM	570RPM	550RPM	500RPM	180RPM
N.W.	13KG	14KG	23KG	23KG	25KGS	30KGS
G.W.	14KG	15KG	28KG	28KG	30KGS	36KGS
Size	42*18.5*42CM	42*18.5*42CM	42*22.5*51CM	42*22.5*51CM	42*22.5*51CM	42*22.5*51CM
