Cayken Multifunctional Oil-Immersed Magnetic Base Drill Machine
Shanghai Chengxiang Electromechanical Equipment Co., Ltd.- Type：Magnetic Drill
- Classification：Magnetic Drill
- Applications：Building and Industrial
- Specification：100mm
- Condition：New
- Customized：Customized
Base Info
- Model NO.：kcy-100,3WDO
- Core Drill Dia：100mm
- Stroke：330mm
- Trademark：Cayken
- Origin：Shanghai
- Production Capacity：5000 Per Month
Description
Basic Info.
Model NO. kcy-100/3WDO Core Drill Dia 100mm Stroke 330mm Trademark Cayken Origin Shanghai Production Capacity 5000 Per MonthProduct Description
| Core drill dia(mm) | 100 |
|---|---|
| Twist drill dia(mm) | 28 |
| Tapping dia(mm) | M26 |
| Rated voltage(v) | 110/220 |
| Rated frequency(Hz) | 50-60 |
| Rated input power(w) | 2380 |
| No-load speed(rpm) | 100-130/300/620 |
| Max attraction(N) | 17600 |
| Cutting Depth(mm) | 70 |
| Stroke(mm) | 330 |
| Packing size(cm) | 62*20*51 |
| Net/Gross weight(kgs) | 27/32 |
