• Model NO.：35AGM
• Specification：See the table below
• Trademark：OEM available
• Origin：China
• HS Code：8205100000
• Production Capacity：50, 000 Pieces , Month

Basic Info.

Model NO. 35AGM Specification See the table below Trademark OEM available Origin China HS Code 8205100000 Production Capacity 50, 000 Pieces / Month

Product Description

Features:
Made from HSS or Cobalt HSS.
CBN precision ground for sharper, burr-free cutting edge.
3 flute design, 90 degree point angle, Morse taper shank.
Suitable for use in steel, cast iron, non-ferrous and light metals.

Coating options: Bright finish, Titanium Nitride coating, TiAlN coating

Size ranges from 15mm to 80mm.

Size	D1 mm	D2 mm	Morse Taper Shank	Overall Length (mm)
15	15	3.2	#1	85
16.5	16.5	3.2	#1	85
19	19	3.5	#2	100
20.5	20.5	3.5	#2	100
23	23	3.8	#2	106
25	25	3.8	#2	106
26	26	3.8	#2	106
28	28	4.0	#2	112
30	30	4.2	#2	112
31	31	4.2	#2	112
34	34	4.5	#2	118
37	37	4.8	#2	118
40	40	10	#3	140
50	50	14	#3	150
63	63	16	#4	180
80	80	22	#4	190
