Portable Angled Type Digital Electric Torque Wrench
Baier Hydraulic Power (Wuhan) Co., Ltd.- Type：Torque Wrench
- Power：Power Source
- Impact Rate：2000ipm
- Torque：100-12000
- Brand：Baier
- Power Supply Type：AC Power
Base Info
- Model NO.：DEWS
- Power Supply Voltage：220V
- Battery Voltage：18V
- Unloaded Speed：1700ipm
- Power Source：Electricity
- Transport Package：Wooden Canse
- Origin：China
- HS Code：8467299000
- Production Capacity：5000,Year
Description
Basic Info.
Model NO. DEWS Power Supply Voltage 220V Battery Voltage 18V Unloaded Speed 1700ipm Power Source Electricity Transport Package Wooden Canse Origin China HS Code 8467299000 Production Capacity 5000/YearProduct Description
Product DescriptionPROTABLE ANGLED TYPE DIGITAL ELECTRIC TORQUE WRENCH
Features:
High output and repeat accuracy: ± 5% and ±3%.
Preset torque and automatic shutoff when reaching the setted torque.
Single-chip intelligent torque control system with LCD display.
With manual 2-speed gearbox, high/low speed can be shifted freely
Very suitable for continuous operation in production assembly and maintenance.
Free connection of power handle and drive unit, could be rotated 360°.
Higher efficiency whether tightening or loosenning bolts and nuts than hydraulic torque wrench.
Portable and durable design, low noise, with overload protection.
After-sales service: 1 year guarantee period, life-long maintenance.
Supply scope :1 pcs torque wrench,1pcs reaction arm,1 copy operating instructions,1 copy test report.
Specifications:
| Model | Min torque(N.m) | Max torque(N.m) | Drive S(mm) | D(mm) | H(mm) | weight(Kg) | Idle speed(rpm) | |
| DEWS-08A | 100 | 800 | 3/4" | 88 | 248 | 8.7 | 20 | |
| DEWS-12A | 200 | 1200 | 1" | 88 | 253 | 8.1 | 18 | |
| DEWS-26A | 400 | 2600 | 1" | 88 | 274 | 9.8 | 7 | |
| DEWS-38A | 500 | 3800 | 11/2" | 96 | 294 | 11.4 | 5 | |
| DEWS-60A | 1000 | 6000 | 11/2" | 114 | 329 | 16.5 | 3.5 | |
| DEWS-80A | 1200 | 8000 | 11/2" | 43 | 390 | 18.4 | 1.9 | |
| DEWS-100A | 1800 | 10000 | 11/2" | 143 | 390 | 20 | 1.6 | |
| DEWS-120A | 2000 | 12000 | 11/2" | 143 | 390 | 20.1 | 1.3 |
