50mm The Professional Magnetic Base Core Drilling Machine (OB-5000)
Shanghai Chengxiang Electromechanical Equipment Co., Ltd.- Type:Magnetic Drill
- Condition:New
- Customized:Customized
- Controlling Mode:Artificial
- Structure:Vertical Drilling Machine
- Layout:Vertical
Base Info
- Model NO.:OB-5000
- Automatic Grade:Automatic
- Precision:High Precision
- RoHS:Red
- Transport Package:Woodencase,Carton
- Specification:CE RoHS
- Trademark:OUBAO
- Origin:Shang Hai China
- Production Capacity:300per Month
Description
Basic Info.
Model NO. OB-5000 Automatic Grade Automatic Precision High Precision RoHS Red Transport Package Woodencase/Carton Specification CE RoHS Trademark OUBAO Origin Shang Hai China Production Capacity 300per MonthProduct Description
Product model: OB-5000Largest drill: 50mm
Rated voltage: 220V
Max attraction: 15500N
Rated input power: 1650W
No-load speed: 570 r/min
1. High power withsmall size and light weight,
2. with constant power soft-starting and electric stepless speed-regulation,
3. with over-loading protection using electic speed-regulation.
4. High adhesion.
5. with coolant and lubricant integrateddevice.
Model | OB-2500 | OB-3500 | OB-5000 | OB-6000 | OB-9000 | OB-1200 |
Max Drilling Dia. | ø25MM | ø35MM | ø50MM | ø60MM | ø90MM | ø120MM |
Rated Voltage | 220V | 220V | 220V | 220V | 220V | 220V |
Magnetic Adhesion | 12800N | 14000N | 15500N | 15800N | 16800N | 19800N |
Input Power | 1400W | 1580W | 1650W | 1680W | 1980W | 2580W |
No-load Speed | 650RPM | 600RPM | 570RPM | 550RPM | 500RPM | 180RPM |
N.W. | 13KG | 14KG | 23KG | 23KG | 25KGS | 30KGS |
G.W. | 14KG | 15KG | 28KG | 28KG | 30KGS | 36KGS |
Size | 42*18.5*42CM | 42*18.5*42CM | 42*22.5*51CM | 42*22.5*51CM | 42*22.5*51CM | 42*22.5*51CM |
