• Model NO.：PZ-1930
• HS Code：8467890000

       Rated crimping force:       24KN       Rated working pressure:       50Mpa       Piston stroke:       35mm       Application:       Copper,Stainless Steel Multilayer composite Pipe,Pex Pipe       Clamping cycle:       3-8s       Working temperature:       -10ºC~40ºC       Battery:       18V 3.0Ah Li-ion       Charger:       100~240V, AC50~60Hz       Charging time:       2Hours       ACCESSORIES:       Battery:       2pcs       Charger:       1pc       Sealing ring of safety valve:       1      Clamp die specification for thin-wall stainless steel pipe,copper pipe(nominal outer diameter)     SV type:15,18,22,28mm Clamp die specification for XPAP

TH type:16,20,26,32mm

U type:16,20,25,32mm

Clamp die specification for PEX15(3/8"),18(1/2"),20(5/8"),24(3/4"),30(1")
