• Model NO.：JC23B-2 JC23B-3
• Impact Drill Head：Adjustable Drill
• Drill shape：Round
• Condition：New
• Customized：Customized
• Core drill：32mm
• Twist dril：23mm,28mm
• motor：1100w,1200w
• Speed：550r,min
• Magnetic adhesion：>14000N
• weight：24kg
• Max.Travel：185mm
• Min. plate thickness：8mm
• Spindle taper：Morse2#
• Rotation angle：Left and right 45°
• Horizontal movement(mm)：20mm
• Transport Package：Carton
• Trademark：HOTONMC
• Origin：Shandong, China
• HS Code：8459290000
• Production Capacity：50 PCS,Month

Basic Info.

Model NO. JC23B-2 JC23B-3 Impact Drill Head Adjustable Drill Drill shape Round Condition New Customized Customized Core drill 32mm Twist dril 23mm,28mm motor 1100w,1200w Speed 550r/min Magnetic adhesion >14000N weight 24kg Max.Travel 185mm Min. plate thickness 8mm Spindle taper Morse2# Rotation angle Left and right 45° Horizontal movement(mm) 20mm Transport Package Carton Trademark HOTONMC Origin Shandong, China HS Code 8459290000 Production Capacity 50 PCS/Month

Product Description

Magnetic Drill:
Magnetic drill also called Magnetic broach drill or Magnetic drill press. Its performance Principle is the Magnetic base adhesive onto the surface of working metal.Then press the working handle downwards and drill through the heaviest beams and steel plating. The magnetic base adhesive power controlled by electric coil that Electromagnetic.Using annular cutters, these drills can punch up to 1-1/2" diameter holes in steel up to 2" thick. They are built with durability and heavy use in mind and feature powerful motors and strong magnetic bases.

Magnetic Drill Usage:
Magnetic drills is a new type of drilling tools, which construction and design very precision and uniform, very potable and universal drilling machine for its light duty. Magnetic base made it very convenient on working Horizontally(water level), vertically, upwards or in high point. Magnetic drills is an ideal machine in steel construction, industrial construction,engineering,equipment reparation, railways, bridges, ship building, crane, metal working, boilers, machinery manufacturing, environmental protection, oil and gas pip line industries


MODEL	JC23B-2 (The base is rotatable)	JC23B-3	JC28A-2 (The base is rotatable)	JC28A-3
Motor power (w)	1100	1100	1200	1200
Voltage	220V,50/60Hz,Single phase	220V,50/60Hz,Single phase	220V,50/60Hz,Single phase	220V,50/60Hz,Single phase
Speed (r/min)	550	550	550	550
Core drill(mm)	Ø32	Ø32	Ø32	Ø32
Twist drill (mm)	Ø23	Ø23	Ø28	Ø28
Max.Travel(mm)	185	185	185	185
Minimum plate thickness(mm)	8	8	8	8
Spindle taper	Morse2#	Morse2#	Morse2#	Morse3#
Magnetic adhesion(N)	>14000	>14000	>15000	>15000
Weight (kg)	24	22	24	22
Rotation angle	Left and right 45°	/	Left and right 45°	/
Horizontal movement(mm)	20	/	20	/

Contact Us:

Wynn TENGZHOU HOTON MACHINERY CO.,LTD   MP:0086 16678336698 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
