Bestlink Diamond Wire Saw Machine for Quarrying

Xiamen Bestlink Factory Co., Ltd.
  • Saw Type：Wire Saw
  • Application：Stone Saw
  • Brand：Bestlink
  • Type：Fixed
  • Power Source：Electricity
  • Customized：Non-Customized

Base Info

  • Model NO.：BL-22G
  • Condition：New
  • Usage：Stone, Rock and Concrete Cutting
  • Voltage：380V , 50Hz
  • Power：11 - 75 Kw
  • Rotation Angle：360 Degree
  • Transport Package：Nude Packing
  • Specification：CE
  • Trademark：BESTLINK
  • Origin：Xiamen, China
  • HS Code：84641090
  • Production Capacity：1000 Sets , Month

Description

TypeBL-11GBL-15GBL-18.5GBL-22GBL-30GBL-37GBL-45GBL-55GBL-75GDriving Motor Power (kw)111518.5223037455575Flywheel's Diameter(mm)5505506506508008008008001000Linear Wire Speed(m/s)0-400-400-400-400-400-400-400-400-40Towable length of wire (m)10-2010-3010-3510-4020-5020-8020-10020-12020-150Feeding Power (kw)0.750.750.750.750.750.750.751.51.5Sideways range (manual)(mm)  200200450450450450650Rotation Angle (Degree celsius) 360360360360  360360 360 360 360 Machine Travelling speed (m/h)0-30 0-30 0-30  0-300-32 0-32 0-32 0-32 0-32 Length of Rail2m*3 2m*32m*32m*32m*32m*32m*3  2m*3  2m*3Power (AC V/Hz)380/50380/50 380/50380/50380/50380/50380/50  380/50380/50Working Temperature Range-15~40 -15~40-15~40-15~40-15~40-15~40-15~40-15~40-15~40  Weight (Tons)0.35  0.370.6 0.7 2.1 2.3 2.6 2.9 3.1

Bestlink Diamond Wire Saw Machine for Quarrying

Bestlink Diamond Wire Saw Machine for Quarrying

Bestlink Diamond Wire Saw Machine for Quarrying
Bestlink Diamond Wire Saw Machine for Quarrying
